Set of Superseal 2 Pin Connector Plugs Male+Female

Set of Superseal 2 Pin Connector Plugs Male+Female

• Long description: This range consists of connector sets suitable with AMP superseal connector systems.
• Connection 1, type – male/female: Female, Male
• Connection type: AMP SuperSeal 2-pin
• Protection class IP: 67
• Series: Superseal
• Operating current: 14 A
• Number of poles: 2
• Cable position type – connection no 1: Straight
• Nominal voltage: 24 V
• Voltage type: DC
• Min. cable cross section: 1 mm²
• Max. cable cross section: 1.5 mm²
• Min. working temperature: -40 °C
• Max working temperature: 125 °C
• Insulated mounting: Yes
