Hexagon Head Set Screw Bolt M12 x 35mm Steel Zinc-plated 10.9

Hexagon Head Set Screw Bolt M12 x 35mm Steel Zinc-plated 10.9

• Long description: Hexagon head set screw, fully threaded, length is measured below the head. ISO 4017 supersedes DIN 933: according to ISO spanner sizes 16, 18, 21 and 34 are for M10, M12, M14 and M22 respectively.
• Thread diameter: M12
• Thread pitch: 1.75 mm
• Length: 35 mm
• Head shape: Hexagon
• Thread type: Metric
• Wrench/Spanner size: 18.0 mm & 19.0 mm
• Head height: 7.5 mm
• Quality: 10.9 (steel)
• Surface treatment: Zinc-plated
• Material: Steel
• DIN standard: 933
• ISO standard: 4017
