Metaltecnica 6″ Ram Vacumm & Spring Assembley Kit

Metaltecnica 6″ Ram Vacumm & Spring Assembley Kit – For use with 6″ Metaltecnica gate valves

• With integrated oil purge
• Port: 3/8″ BSP Male
• Brand: MZ
• Spring loaded hydraulic ram with expansion spring
• Finish: Zinc plated
• Type: Expansion spring
• Weight 5.338kg
• Technical info: Max. 200 bar
• Stroke: 187 mm
• Min. length: 445 mm
• Max. working pressure: 200 BAR
• Mounting thread diameter – cylinder connection: M30
• Mounting thread pitch – cylinder connection: 2.00 mm
• Outside diameter: 70 mm



Weight	5.338 kg
part number	Suitable for gate valves: G8870, G8871, G16698, G12272, G16645 and G12273
